CONSTANT CURRENT LED DRIVER - SINGLE OUTPUT - 350 mA - 25 W

€26.95
Availability: In stock or 3 working days
SKU
VL_APC-35-500
More Information
Height6.500000
External IdAPC-35-500
EAN5410329681586
PackagingBoîte
Width13.000000
Depth3.500000
Product basic info
  • Primary colours: White
  • Additional colours: Black, Red
  • Depth unit: 84 mm
  • Height unit: 29.5 mm
  • Width unit: 57 mm
  • Weight unit: 165 g
Physical properties
  • Number of outputs: 1
  • Housing type: Enclosed
Electrical data
  • Output power rating: 35 W
  • Output current rating: 350 mA
Technical data
  • Dimmable: No
  • Series LED driver: APC
  • Input efficiency: 84 %
Set-up options
  • Dimming type: No dimming
Environmental data
  • IP rating: IP30
Power supply
  • Input voltage rating VAC range: 90-264 V
  • Input voltage rating VDC range: 127-370 V
  • Input current rating: 0.4 A
  • Output voltage rating VDC range: 25-70 V
  • Technology type: Constant current mode
  • courant continu
  • entrée CA universelle / plage complète
  • supporte entrées de 300 VCA durant 5 secondes
  • protection contre: court-circuit / surtension
  • boîtier en plastique complètement isolé
  • compact et léger
  • refroidissement: convection naturelle
  • IP30
  • prétesté sur 100 % de la puissance
  • convient à l'éclairage LED et journaux lumineux
  • économique / haute fiabilité
  • 2 ans de garantie
