Industrial DIN-rail power supply - single output - 30 W - 24 V - 1.5 A
€22.95
Availability: In stock or 3 working days
SKU
VL_LI30-20B24PR2
MORNSUN, is a leading industrial power supply manufacturer and produces high-quality products. The company was founded in 1998. This industrial DIN-rail power supply from Mornsun is a cost-effective, energy-efficient solution for standard DIN-rail mounting. The products offer a high level of stability and comply with international IEC62368 standards for EMC and safety standards meet IEC/EN61000-4, CISPR32/EN55032, UL62368, EN62368, IEC/EN61010, IEC/EN61558 and IEC60335.
| Height | 6.200000 |
|---|---|
| External Id | LI30-20B24PR2 |
| EAN | 5410329756451 |
| Packaging | Boîte |
| Width | 9.800000 |
| Depth | 3.800000 |
Product basic info
- Instruction manual languages: English
- Primary colours: Black
- Depth unit: 59 mm
- Height unit: 92.66 mm
- Width unit: 35 mm
- Weight unit: 115 g
- Material: ABS, heat resistant (UL94V-0)
Physical properties
- Number of outputs: 1
Electrical data
- Output power rating: 36 W
- Output current rating: 1.5 A
Technical data
- Mounting type: DIN-rail mounting
- Input efficiency: 88 %
- Power supply series: LI
Environmental data
- IP rating: IP20
- Usage location: Indoor only
Power supply
- Output voltage rating VDC: 24 V
- Input voltage rating VAC range: 85-264 V
- Input voltage rating VDC range: 120-370 V
- Input current rating at 115 VAC: 0.9 A
- Input current rating at 230 VAC: 0.5 A
- Input frequency range: 47-63 Hz
