ITE SWITCHING POWER SUPPLY - SINGLE OUTPUT - 75 W - 5 V - CLOSED FRAME - FOR PROFESSIONAL USE ONLY
€27.95
Availability: In stock or 3 working days
SKU
VL_LRS-75-5
| Height | 10.000000 |
|---|---|
| External Id | LRS-75-5 |
| EAN | 8720207841863 |
| Packaging | Boîte |
| Width | 10.000000 |
| Depth | 3.500000 |
Product basic info
- Instruction manual languages: English
- Primary colours: Grey
- Primary detailed colours: Metal
- Depth unit: 99 mm
- Height unit: 30 mm
- Width unit: 97 mm
- Weight unit: 250 g
- Material: Metal
Physical properties
- Number of outputs: 1
- Housing type: Open
Electrical data
- Output power rating: 75 W
- Output current rating: 14 A
- Electrical protection: Overload, Overvoltage, Short-circuit
Technical data
- Mounting type: Screw mounting
- Input efficiency: 86.5 %
- Power supply series: LRS
Environmental data
- IP rating: IP20
- Usage location: Indoor only
Power supply
- Output voltage rating VDC: 5 V
- Input voltage rating VAC range: 85-264 V
- Input voltage rating VDC range: 120-373 V
- Technology type: Constant voltage mode
- Input current rating at 115 VAC: 1.4 A
- Input current rating at 230 VAC: 0.85 A
- Input frequency range: 47-63 Hz
- entrée CA universelle / plage complète
- supporte entrées de 300 VCA durant 5 secondesv
- consommation à vide < 0.2 W
- compacte et profil bas 1U
- convient à des températures de service élevées jusqu'à 70 °C
- refroidissement: convection naturelle
- altitude de fonctionnement max. 5000 m
- conforme au test de vibration 5G
- haut rendement, durée de vie prolongée, haute fiabilité
- 3 ans de garantie
- protections: court-circuit / surcharge / surtension
- prétestée sur 100 % de la puissance
- indicateur LED d'alimentation
- couvercle pour bornier non inclus
